What is the use of base jack in scaffolding?

What is Base Jack?

Goto Gongde to know more.

Scaffolding screw base jack is made of screw tube and sheet metal plate, and assembled with casted or forged nut. The application is support scaffolding system, ringlock scaffolding system, cuplock scaffolding system, kwikstage scaffolding system, haki scaffolding system, tube&clamp scaffolding system and also formwork system, adjusting the construction system height flexibly.

Construction is usually carried out at a height above the ground. Scaffolding is used to provide a stable and secure working platform for construction workers on the ground or where ladders or lifting devices cannot reach.

adjustable base jack for scaffoldings

Scaffolding is usually considered a temporary structure entered by internal or external workers. Many workplaces are uneven, and scaffolding adjustable base jacks help to provide a safe and level working surface at a variety of working heights on the ground.

A base jack is used to hold scaffolding in place horizontally. The adjustable screw jack is mounted on a stable base and contains a large adjustable screw for moving scaffolding up and down. After scaffolding is built, use base jack scaffold to level the working platform before use. Adjustable U-Head Jacks are designed to be used in conjunction with adjustable system scaffolding. The main function of adjustable U-Head jack is to hold timber beams securely in place.

welding of jack base

packing of scaffolding jack bases

The scaffolding base jack (screw jack) is used as the starting base of the scaffold, and provides stability by adjusting the jack nut of the base on uneven ground, and is used for level adjustment of the system scaffolding according to different underground heights. Adjustable base jack are also called adjustable screw jacks, scaffold jacks, leveling jacks, base jacks or jack bases, etc.

If you want to learn more, please visit our website Scaffolding Steel Soild U Head Base Jack.

What is the use of base jack in scaffolding?

A base jack is also sometimes called a leveling jack or screw leg. They are designed to provide a level foundation for your scaffolding platform. The bottom of the base jack has a 4" X 4" fixed bottom plate as a foot. This base plate is designed to be fastened (by nails or screws) to a wood clay base plate. These jacks can be raised up to 12" to ensure the scaffolding platform is level. They work like a giant screw where the base of the scaffolding frame rests on a nut that can be raised or lowered by turning clockwise or counterclockwise. The maximum of the base jack The extended height is 18". Most base jacks have a built-in stop so that the maximum height will not be exceeded. (For mobile scaffolding, the maximum height of the base jack is 12".) The jack is secured to the on the scaffolding frame.

Why choose EKscaffold adjustable base jack

EKscaffold can design scaffolding with adjustable base jack according to customer requirements. In addition, the base jack of EKscaffold has passed the EN scaffolding standard certification. Our QC team controls the quality of adjustable base jack for scaffolding according to ISO in terms of raw material testing, welding quality and safe load capacity.

EKscaffold's scaffolding adjustable base jack can be electro-galvanized or hot-dip galvanized to meet different durability requirements and construction project budget plans, and is tested to ensure compliance with OSHA standards. For more information, please feel free to contact us.

Are you interested in learning more about Scaffold Swivel Base Jack? Contact us today to secure an expert consultation!
