Here are 5 benefits of cold working of steels that make a difference to your machining operations.
You can find more information on our web, so please take a look.
Increased Strength
It is widely known that cold working strain changes the properties of most metals. When as rolled steel bars are cold worked by cold drawing through a die, a significant increase in yield and tensile strength is obtained. At the same time, The reduction in area and percent elongation are reduced.
The graph below shows the effect of cold drawing on the tensile properties of 1 inch round diameter steel bars.
There are two important lessons in this graph: 1) As strength properties increase, ductility measures decrease; 2) Up to about 15% cold reduction, yield strength increases at a much greater rate than tensile strength. The first 5% of cold work results in the greatest increase in strength.
Improved Surface Finish
Hot rolled steel bars are finished at high temperatures, and so the surface has a hard abrasive scale made up of various oxides of Iron. This scale is hard and abrasive ranging from 270 &#; DPH (Vickers) microhardness depending on the type of oxide (s) formed. In order to cold draw the bars, cold finshers typically remove the sacle by shot blasting or acid pickling. This results in the removal of the hard abrasive scale.
By pulling the bars though the die, the surface finish is also improved, with Cold Drawn bars typically running 50 microinches maximum and modern equipment typically working at 25-30 micro inches. Compare this to a roughness height of 250 or more for hot rolled bars.
Controlled Dimensions
Because the bars are cold reduced at room temperature by pulling through an oil lubricated die, the dimensional conformance of the steel is much more easily controlled. Typical tolerances for cold drawn 1 &#; low carbon steel bars are +0.000&#;/ &#; 0.002&#;. this compares favorably to +/- 0.010 for hot rolled steel of the same chemistry and diameter. Concentricity is improved by the cold drawing operation.
Improved Straightness
The straightness of hot roll bars is generally 1/4&#; max deviation in any 5 foot length. In cold drawn bars, depending on size and grade this deviation can be held to as little as 1/16&#; in 10 feet.
Please see our post here for a more complete discussion of bar straightness.
Improved Machinability
Improved machinability is really the synergistic result of all of the above improvements made by cold work (cold drawing).
Higher yield to tensile ratio means the tool has less work to do to move the metal in the workpiece to its ultimate strength when it will separate as a chip. This translates into less force on the tool and greater tool life and productivity. Not putting hard abrasive scale and oxides into your cutting fluids nor on to your tool because the bar has been cleaned results in longer uptime and less maintenance for tools, workholding, and machines. More tightly controlled dimensions and concentricity means that the bars can be run at higher speeds without creating harmful vibrations and chatter. Finer tolerances can be held by your equipment when bars are sized properly going into the machine. Similarly, improved straightness results in less runout and permits higher speeds in production.
Bottom line: Hot roll bars may be cheaper by the pound, but machining them will cost your company a lot more because they lack the benefits of cold drawing:
Graph and data: AISI Cold Finished Steel Bar Handbook, . (Out of print)
Drawing a tube from one size to another sounds simple. The process has two main steps: crushing one end (also known as pointing the tube), then drawing it through a die that has the correct ID. When the process is finished, the tube&#;s OD matches the die&#;s ID.
In reality, it&#;s much more complicated than that. A successful draw is a product of five distinct steps:
Tubing for redrawing can be either welded or seamless. The redrawing process for each is essentially the same; therefore, processes described in this article apply to both.
Welded tubing is produced from strip that has been rolled, slit, and coiled. After the coil is delivered to the tube production facility, it is uncoiled and fed into a mill that forms it into a tubular shape and the resultant seam is welded. Carbon and low-alloy steels usually are electric resistance welded (ERW), whereas stainless steels are gas tungsten arc welded (GTAW).
Seamless tubing may originate from pierced tubing (carbon or low-alloy steel) or extrusions (stainless, high-alloy steels, and nickel-based alloys). They may be further processed by pilgering or reducing. Another raw material is a drilled bar, which usually is used for special alloys or tolerances.
While the equipment and procedures discussed here may be applicable to most alloys, they are aimed primarily at carbon and low-alloy steel, stainless steel, and nickel-based alloys. Copper and aluminum usually are produced by high-volume processes, while titanium and zirconium alloys are better suited to low-volume, specialized processes such as pilgering and tube rolling.
Drawing begins with procuring the raw material. The purchase order should specify the material&#;s chemistry and dimensions including tolerances&#;size, wall thickness, concentricity, and straightness. In most cases, the annealed properties are specified for maximum softness. These requirements may be included in a proprietary specification or an ASTM, AMS, or MIL code or specification.
The next step is pointing, which is the process of decreasing the diameter of several inches of material at the tube&#;s end so it can enter the drawing die. The three most common methods for pointing are push pointing, rotary swaging, and squeeze pointing. In some cases, phosphate coating or soap film is applied before drawing.
Draw benches are usually mechanical and have three components: a back bench, die head, and front section. Jaws on a trolley grip the tube and a hook on the back of the trolley engages a moving chain, pulling the tube through a die. Dies are most commonly sintered tungsten carbide inserts with a cobalt binder that have been shrunk-fit into a steel casing.
Tubes are drawn to a finished size using one or more of the following operations:
Rod Drawing. During rod drawing, a hardened steel mandrel is inserted into the bore of the tube that has been pointed. After the tube has been introduced into the die (see Figure 1), lubricating oil is pumped onto the surface of the tube, the trolley jaws grip the tube or rod tip, the trolley hook engages the chain, and the tube is drawn through the die. The die diameter determines the OD; the rod diameter determines the ID size. Proper die selection minimizes wall thickness changes before the tube contacts the mandrel.
For more information, please visit Xingtai Steel.
Featured content:In general, heavy-wall tubes tend to thin before contacting the rod; light walls thicken. High-angle dies tend to thin the wall and low-angle dies tend to thicken the wall. It is critical to remember that the optimum die angle varies with the diameter-to-thickness (D/t) ratio.
After the tube is drawn, it must be expanded for rod removal. A common method is to apply pressure by rotating the tube while passing it through cross rolls. This process generates radial stresses and expands the tube. The process is repeated until the tube is at finished size.
Advantages of rod drawing are that drawing speeds are relatively high and high area reductions (approximately 45 percent for stainless steel) are possible. Disadvantages are that it is a two-person operation and it requires an additional drawing operation, such as a plug draw or sinking, to remove the spiral pattern.
Plug Drawing. Two varieties of plug drawing are fixed and floating. Fixed plug drawing uses a hollow rod anchored at the back of the bench. A lubricant is pumped through the rod to a small hole near the front, allowing lubricant to enter the ID of the tube. A slightly tapered tungsten carbide plug is threaded or brazed onto the end of the rod; the tube is loaded over the rod, lubricant pumped onto the OD surface, and the tube is drawn.
One of the benefits of fixed plug drawing (see Figure 2) is that it produces a smooth ID. Another advantage is that the taper makes it possible to adjust the ID to meet a tight tolerance. While it requires only one operator, the drawing speed is quite slow, and maximum area reductions are low&#;about 25 percent for stainless steel.
Floating plug drawing (see Figure 3) is well-suited to producing long-length coils economically. This method was used for drawing copper and aluminum for many years. After the lubricant is pumped into the ID of the tube, a tapered plug is inserted, the tube is crimped to hold the plug in place, and the tube is pointed. During drawing the plug is held in position by a combination of forces between the tube ID and the plug. The tooling design is critical to the success of this process. Die angles are generally between 28 and 32 degrees, with plug angles between 20 and 24 degrees. The bearing length should be about 10 to 15 percent of die diameter. Be aware that a plug that is too long can cause scratches on the ID; a plug that is too short will not seat.
Semifloating drawing and tethered plug drawing are floating plug processes adapted for drawing straight lengths. The plug is attached loosely to a back rod and the tube is loaded over the rod and plug for drawing (see Figure 4).
Sinking. Sinking is the term for drawing a tube with no internal support. It is usually performed as a sizing pass after a rod draw. The proper die angle depends on theD/t ratio; a properly chosen die angle minimizes the change in wall thickness. If the wall thickens too much, the ID surface finish will deteriorate.
The bearing length is longer than with other operations, up to 50 percent of the die&#;s diameter, to ensure the roundness of the finished tube.
Plug drawing and sinking can be used to draw a tube to a finished size.
When designing a drawing schedule, the ratio of wall reduction to diameter reduction is an important quality consideration. Wall reductions tend to iron, or smooth, the ID surface; diameter reductions tend to roughen the surface. A convenient expression for the ratio is the Q value, which is equal to the perce nt wall reduction divided by the percent ID reduction. A Q value of 2 or higher tends to smooth the ID surface. When the schedule does not lend itself to a series of high-Q-value draws, it is better to use a high-Q-value rod draw followed by a hard sink rather than a series of low-Q-value drawing operations. High Q values also result in low residual stress levels for cold-worked tubes. In a recent project, a Q value of 0.91 yielded a residual stress of more than 52,000 pounds per square inch (PSI) as measured by the Sachs and Espy procedure described in ASTM E. A draw with a Q value of 2.2 had a residual stress level of only 5,200 PSI. High Q values would result in negative, or compressive, values.
Lubrication. Lubrication is another important consideration, along with tooling and drawing schedule. Most tube mills use chlorinated oils for lubricating stainless steels and nickel alloys. The correct viscosity can be as low as 8,000 SUS (Saybolt Universal Seconds) or more than 100,000 SUS depending on the alloy, tube size, and type of reduction.
Straightening is usually performed using a six- or 10-roll rotary straightener (see Figure 5) with a combination of flex and pressure. While flex has little effect on properties, pressure tends to increase yield strength and raise the residual stress level. Exerting the minimal pressure is the best practice.
Finishing operations may include polishing, pickling, or sandblasting to improve the surface appearance and remove minor imperfections. Final inspection techniques are determined by the customers&#; order requirements.
The editors of TPJ-The Tube & Pipe Journal® thank the Tube & Pipe Association, International®&#;s Extrusion, Drawing & Tube Reducing Technology Council for its efforts in arranging the publication of this article.
