The dredging rubber hoses are suitable for dredging sand & slurry. It is normally installed between the HDPE dredging pipes to ensure the whole pipelines more flexible. SINCO Pipe could supply dredging rubber hoses ranging from 100mm inner diameter to 900mm inner diameter with various length and pressure ratings.
If you want to learn more, please visit our website.
Dredging Rubber Hose Specifications
Dredging Rubber Hose Specification
Material: EPDM, Natural Rubber, Silicon, FKM, NBR,SBR etc.
Color: Black or Customized
Tolerance: ±0.05m
Density:1.0-2.0g/cm3
Inner Diameter (mm)
Total Length (mm)
Working Pressure (Mpa)
100
1000
1.0
150
1000
1.0
200
1200
1.2
250
1200
1.2
300
1200
1.2
350
1200
1.2
406
1200
1.5
456
1300
1.5
506
1400
1.6
556
1500
1.8
606
1500
1.8
650
1600
1.8
706
1800
1.8
756
1800
2.0
800
2000
2.0
850
2000
2.5
900
2000
2.8
NOTES: Working Pressure & Flanges could be customized.
Dredging Rubber Hose Technical Properties
Dredging Rubber Hose Technical Properties
Items
HESPER are exported all over the world and different industries with quality first. Our belief is to provide our customers with more and better high value-added products. Let's create a better future together.
Index
Notes
Working Pressure (Mpa)
≥0.80
1-The technical data shows here just follows the standard of HG-T2185-9.
2-The strength layer is 200D/3 cord fabric and the pulling force is 380N for each single root.
Test Pressure (Mpa)
≥1.2
Burst Pressure(Mpa)
≥2.4
Conveying Medium
Muddy, Water
Tensile Strength(Mpa)
≥11.80MPa
Elongation(%)
≥400
Ozone Testing
No Cracking in 48 hours exposed in Ozone
Abrasion
≤0.395cm3
Ageing Resistance
Ageing Resistance
Shore Hardness A
63±3
Adhesion Strength Between Each Layer(KN/m)
≥1.0
Strength Layer
4 layers of cord fabric
Dredging Rubber Hose Advantages
The dredging rubber hose is suitable for dredging engineering projects .It is consist out of an inner lining which can be adjusted to meet the specific requirement of the transported medium. Wear indicator layers can also be implemented in the lining of the hoses which transport abrasive medium. A proven textile reinforcement of high tensile strength controls the pressure resistance of the hose as well as its tensile strength. Whereas the outer cover is built up utilizing a rubber compound formulated to be highly resistant against weathering, UV light and ozone attack. On special request the outer cover can be built utilizing oil resistant materials. Hose end fittings are available in a wide range of designs specifically produced to match the selected hose service requirements. The dredging rubber hose main features as follows:
1. Dredging rubber hose outer cover with excellent aging resistance and corrosion resistance.
2. Dredging rubber hose inner cover with excellent abrasion resistance and high quality.
3. Wearing colored indicator layer.
4. Bending angle in working condition is from 0-45.
5. Low centre of gravity, strong ability of the anti-wave and good stability.
Vonehoses
·
Follow
4 min read
·
Jan 5, 2023
--
There are many options when it comes to dredging equipment. There are a wide variety of brands, but you also have the option of choosing between rubber hoses and steel hoses. This is great if you are trying to find a hose that is both durable and affordable.
Dredging hose can be described as a flexible rubber hose that is used for many purposes. This includes hoses for steam sewer, paint, furnace, and more. These hoses come in a variety of sizes and specifications. One of the best examples is the hoses by Salem-Republic Rubber Company, a leading manufacturer of dredge hoses and related products and services.
The salem-Republic Rubber Company is a proud member the rubber community. Their dredgehoses are made of the best quality materials and are designed to meet the needs of the dredging sector. As such, they are known as a single source dredge hose manufacturer. They are also known for their innovative product designs. In addition to offering a complete hose assembly, they can also offer custom hose solutions tailored to your individual needs.
Salem-Republic’s dredginghose is a popular product. Their hoses are well-known for their quality and durability. For example, their tough hard suction hose features a custom-blended rubber lining to resist abrasion and provide a tougher hose for dredging tasks. Other notable features include a 1 to 59-inch bend radius, an SBR coverage, and a 2-year limited warranty.
Aside from their dredge hoses, the Salem-Republic Rubber Company is also a premier producer of general purpose air and water hoses. If you’re in the market for a new hose, don’t hesitate to contact them for a quote.
Dredge rubber hoses are mainly made of natural or synthetic rubber. It is used to connect pipes or other devices. This hose is heat and abrasion resistant.
These hoses can be installed quickly and are flexible. They can be used in high or low pressure applications. Rubber hoses should be kept clean. Avoid using the hose when handling toxic materials. Also, check that the hose is properly cut.
Rubber hoses come in many sizes and types. Choose the one that will suit your application. There are many options available: regular hose or floating hose; oxygen hose, compressor, hose, water hose and oxygen hose. It is important to choose the right one for durability.
Rubber hoses can be flexible and abrasion-resistant. They are often installed between HDPE pipes. But, they should be checked regularly to avoid damage. The wrong type of hose could cause serious damage.
Rubber hoses come in a variety of lengths and styles. Some are heated electrically. Depending on the size, the hose can have a bend radius of up to 59 inches. A few are FDA approved.
Dredge rubber hoses are flexible and durable. The inner layer of the hose is made of new tackifying resins. Ceramic materials are also used to improve wear resistance and reduce working energy consumption.
Dredge discharge hose, a flexible rubber hose, is used to connect a drill to a pump. The hose is used in a variety of applications such as dredging, drainage, paint, furnace and welding. There are many sizes and specifications available. PVC, natural rubber, and composites are some of the most common materials.
A dredge discharge hose is a good way to transfer slurry, mud, corrosive liquids and corrosive solids in a safe and efficient manner. Various features are present in the hose such as a heavy duty wall, a smooth bend and an abrasion-resistant cover. There are many types of dredge-hoses available today. Some of them come with a standard ANSI 150 PSI fixed flange and an inner rubber liner with an abrasion-resistant hose rubber.
One of the more interesting hoses is a flared hose. Flared hoses have a thicker wall, which allows them to reach water depths up to 30 meters. This hose is a good choice for sand mining or heavy duty dredging operations. They are also economical. These hoses are used to transport clay and finesand, especially in harsh marine environments.
Although it is not a true multipurpose hose, it is the right size and the right material for a range of applications. It is the best type of hose for a dredge, as it is easy to install, is not prone to leaks and offers a high degree of abrasion resistance.
Featured content:The dredging rubber hosedredging rubber hoses are suitable for dredging sand & slurry. It is normally installed between the HDPE dredging pipes to ensure the whole pipelines more flexible. SINCO Pipe could supply dredging rubber hoses ranging from 100mm inner diameter to 900mm inner diameter with various length and pressure ratings.
Dredging Rubber Hose Specifications
Dredging Rubber Hose Specification
Material: EPDM, Natural Rubber, Silicon, FKM, NBR,SBR etc.
Color: Black or Customized
Tolerance: ±0.05m
Density:1.0-2.0g/cm3
Inner Diameter (mm)
Total Length (mm)
Working Pressure (Mpa)
100
1000
1.0
150
1000
1.0
200
1200
1.2
250
1200
1.2
300
1200
1.2
350
1200
1.2
406
1200
1.5
456
1300
1.5
506
1400
1.6
556
1500
1.8
606
1500
1.8
650
1600
1.8
706
1800
1.8
756
1800
2.0
800
2000
2.0
850
2000
2.5
900
2000
2.8
NOTES: Working Pressure & Flanges could be customized.
Dredging Rubber Hose Technical Properties
Dredging Rubber Hose Technical Properties
Items
Index
Notes
Working Pressure (Mpa)
≥0.80
1-The technical data shows here just follows the standard of HG-T2185-9.
2-The strength layer is 200D/3 cord fabric and the pulling force is 380N for each single root.
Test Pressure (Mpa)
≥1.2
Burst Pressure(Mpa)
≥2.4
Conveying Medium
Muddy, Water
Tensile Strength(Mpa)
≥11.80MPa
Elongation(%)
≥400
Ozone Testing
No Cracking in 48 hours exposed in Ozone
Abrasion
≤0.395cm3
Ageing Resistance
Ageing Resistance
Shore Hardness A
63±3
Adhesion Strength Between Each Layer(KN/m)
≥1.0
Strength Layer
4 layers of cord fabric
Dredging Rubber Hose Advantages
The dredging rubber hose is suitable for dredging engineering projects .It is consist out of an inner lining which can be adjusted to meet the specific requirement of the transported medium. Wear indicator layers can also be implemented in the lining of the hoses which transport abrasive medium. A proven textile reinforcement of high tensile strength controls the pressure resistance of the hose as well as its tensile strength. Whereas the outer cover is built up utilizing a rubber compound formulated to be highly resistant against weathering, UV light and ozone attack. On special request the outer cover can be built utilizing oil resistant materials. Hose end fittings are available in a wide range of designs specifically produced to match the selected hose service requirements. The dredging rubber hose main features as follows:
1. Dredging rubber hose outer cover with excellent aging resistance and corrosion resistance.
2. Dredging rubber hose inner cover with excellent abrasion resistance and high quality.
3. Wearing colored indicator layer.
4. Bending angle in working condition is from 0-45.
5. Low centre of gravity, strong ability of the anti-wave and good stability.
Vonehoses
·
Follow
4 min read
·
Jan 5, 2023
--
There are many options when it comes to dredging equipment. There are a wide variety of brands, but you also have the option of choosing between rubber hoses and steel hoses. This is great if you are trying to find a hose that is both durable and affordable.
Dredging hose can be described as a flexible rubber hose that is used for many purposes. This includes hoses for steam sewer, paint, furnace, and more. These hoses come in a variety of sizes and specifications. One of the best examples is the hoses by Salem-Republic Rubber Company, a leading manufacturer of dredge hoses and related products and services.
The salem-Republic Rubber Company is a proud member the rubber community. Their dredgehoses are made of the best quality materials and are designed to meet the needs of the dredging sector. As such, they are known as a single source dredge hose manufacturer. They are also known for their innovative product designs. In addition to offering a complete hose assembly, they can also offer custom hose solutions tailored to your individual needs.
Salem-Republic’s dredginghose is a popular product. Their hoses are well-known for their quality and durability. For example, their tough hard suction hose features a custom-blended rubber lining to resist abrasion and provide a tougher hose for dredging tasks. Other notable features include a 1 to 59-inch bend radius, an SBR coverage, and a 2-year limited warranty.
Aside from their dredge hoses, the Salem-Republic Rubber Company is also a premier producer of general purpose air and water hoses. If you’re in the market for a new hose, don’t hesitate to contact them for a quote.
Dredge rubber hoses are mainly made of natural or synthetic rubber. It is used to connect pipes or other devices. This hose is heat and abrasion resistant.
These hoses can be installed quickly and are flexible. They can be used in high or low pressure applications. Rubber hoses should be kept clean. Avoid using the hose when handling toxic materials. Also, check that the hose is properly cut.
Rubber hoses come in many sizes and types. Choose the one that will suit your application. There are many options available: regular hose or floating hose; oxygen hose, compressor, hose, water hose and oxygen hose. It is important to choose the right one for durability.
Rubber hoses can be flexible and abrasion-resistant. They are often installed between HDPE pipes. But, they should be checked regularly to avoid damage. The wrong type of hose could cause serious damage.
Rubber hoses come in a variety of lengths and styles. Some are heated electrically. Depending on the size, the hose can have a bend radius of up to 59 inches. A few are FDA approved.
Dredge rubber hoses are flexible and durable. The inner layer of the hose is made of new tackifying resins. Ceramic materials are also used to improve wear resistance and reduce working energy consumption.
Dredge discharge hose, a flexible rubber hose, is used to connect a drill to a pump. The hose is used in a variety of applications such as dredging, drainage, paint, furnace and welding. There are many sizes and specifications available. PVC, natural rubber, and composites are some of the most common materials.
A dredge discharge hose is a good way to transfer slurry, mud, corrosive liquids and corrosive solids in a safe and efficient manner. Various features are present in the hose such as a heavy duty wall, a smooth bend and an abrasion-resistant cover. There are many types of dredge-hoses available today. Some of them come with a standard ANSI 150 PSI fixed flange and an inner rubber liner with an abrasion-resistant hose rubber.
One of the more interesting hoses is a flared hose. Flared hoses have a thicker wall, which allows them to reach water depths up to 30 meters. This hose is a good choice for sand mining or heavy duty dredging operations. They are also economical. These hoses are used to transport clay and finesand, especially in harsh marine environments.
Although it is not a true multipurpose hose, it is the right size and the right material for a range of applications. It is the best type of hose for a dredge, as it is easy to install, is not prone to leaks and offers a high degree of abrasion resistance.
